ReidBar™ IPort Flange Anchor System

RRP $0.00
    • Description
    • Features
    • Documents
    • Digital Downloads
    • Videos


    The ReidBar™ iPort Flange Anchor System provides a tested and Bridge Code compliant headed anchorage solution with an improved epoxy injection system supporting increased quality control, safe handling of epoxy and simplified labour efficient installation.

    Available in steel, a ReidBar™ threaded anchoring solution that is independently tested to demonstrate compliance with the performance requirements of NZS 3101 Amendment 3 and of the NZTA Bridge Manual 3rd Edition Amendment 4 is now available to the New Zealand market.

    System Components:

    • Genuine ReidBar™ Bar
    • ReidBar™ Flange Anchor
    • ReidBar™ Half Nut


    What is Genuine ReidBar™: Genuine ReidBar™ is a continuously threaded, hot rolled Grade 500E reinforcing bar manufactured in New Zealand in accordance with AS/NZS 4671:2019.  Genuine ReidBar™ Connection Systems deliver Optimised Reinforcing Connection solutions designed to increase structural system integrity, simplify complex connections and reduce overall application costs.

    All ReidBar™ Bar and ReidBar™ Connection Systems are manufactured within quality-controlled tolerances (ISO:9001) and tested In-Concrete via 3rd Party verification ensuring performance as a Genuine matched reinforcing system.



    Features And Benefits:

    • Compact headed anchor system which allows anchoring of reinforcing at heavily congested construction joints, such as pile caps and beam column joints.
    • Provides alternative anchoring option when there is insufficient space for standard hooks.
    • Flange Design for true headed anchor capacity.
    • Injection “iPort” epoxy delivery system.
    • Injection “iPort” allows for additional Mid Bar applications.
    • Coarse threaded system requires no post threading.
    • Injection process provides a visual indicator of installed quality.
    File Type File Description
    Reid ReidBar iPort Flange Anchor Product Guide NZ 23 Product GuidesThe ReidBar™ iPort Flange Anchor provides a tested and Bridge Code complaint headed anchorage solution with an improved epoxy injection system supporting increased quality control, safe handling of epoxy and simplified labour efficient installation.
    Reid ReidBar iPort Flange Anchor Compliance Document NZ Compliance DocumentsIndependently tested to demonstrate compliance with the performance requirements of NZS 3101 Amendment 3 and of the NZTA Bridge Manual 3rd Edition Amendment 4
    ReidBar™ iPort Flange Anchor System External Bulletin Product Bulletins Acting on industry feedback regarding the existing system, it was found the ReidBar™ Steel Flange Nut was limited in its ability to cleanly deliver the epoxy between the bar and fitting, often resulting in excess epoxy residue as the fitting was wound
    Reid iPort Flange Anchor RTA Document Technical Assessment DocumentsThis Technical Assessment meets the testing requirements stipulated in clauses 8.7.5.2 (b), 8.9.1.3 (a), (b), 8.6.11.1,2,3 & 4 of NZS 3101:2006 A3
    File Type File Description
    ReidBar Half Nuts DWG Digital DownloadsReidBar Half Nuts DWG
    ReidBar Half Nuts RFA Digital Downloads ReidBar Half Nuts RFA
    Reid™ ReidBar™ iPort™ Flange Anchor

    The ReidBar™ iPort Flange Anchor provides a tested and Bridge Code complaint headed anchorage solution with an improved epoxy injection system supporting increased quality control, safe handling of epoxy and simplified labour efficient installation.

    Reid™ ReidBar™ IPort Flange Anchor

    Reid™ ReidBar™ IPort Flange Anchor:

    Part No.DescriptionFoot diameter
    (A) (mm)
    Length
    (B) (mm)
    Body Diameter
    (C) (mm)
    Hex Size A/F (mm)
    RB12FAIPSREIDBAR 12MM FLANGE ANCHOR IPORT STEEL39502222.6
    RB12FAIPSGREIDBAR 12MM FLANGE ANCHOR IPORT STEEL GALV39502222.6
    RBA16FAIPSREIDBAR 16MM FLANGE ANCHOR IPORT STEEL58503536
    RBA16FAIPSGREIDBAR 16MM FLANGE ANCHOR IPORT STEEL GALV58503636
    RB20FAIPSREIDBAR 20MM FLANGE ANCHOR IPORT STEEL67503536
    RB20FAIPSGREIDBAR 20MM FLANGE ANCHOR IPORT STEEL GALV67503536
    RB25FAIPSREIDBAR 25MM FLANGE ANCHOR IPORT STEEL83804242
    RB25FAIPSGREIDBAR 25MM FLANGE ANCHOR IPORT STEEL GALV83804242
    RB32FAIPSREIDBAR 32MM FLANGE ANCHOR IPORT STEEL92955557
    RB32FAIPSGREIDBAR 32MM FLANGE ANCHOR IPORT STEEL GALV92955557
    Reid™ ReidBar™ Half Nut

    Reid™ ReidBar™ Half Nut:

    Part No.Description
    RB12NHG12mm ReidBar Half Nut (Galv.)
    RBA16NHG16mm ReidBar Half Nut (Galv.)
    RB20NHG20mm ReidBar Half Nut (Galv.)
    RB25NHG25mm ReidBar Half Nut (Galv.)
    RB32NHG32mm ReidBar Half Nut (Galv.)

    Featured Video

    Reid™ ReidBar™ iPort™ Flange Anchor

    The ReidBar™ iPort Flange Anchor provides a tested and Bridge Code complaint headed anchorage solution with an improved epoxy injection system supporting increased quality control, safe handling of epoxy and simplified labour efficient installation.

    View Video
    Reid™ ReidBar™ iPort™ Flange Anchor
