Reid™ Threaded Metric Inserts

RRP $0.00
    • Description
    • Features
    • Documents



    Threaded Inserts are designed for casting into concrete and providing fixing points for the attachment of structural members and ancillary fittings to be bolted directly to the concrete structure. Reid supply a range of threaded inserts from M10 to M24 in zinc, hot dipped galvanised and 316 Stainless Steel finishes.



    Reid Threaded Metric Inserts (TIMS) are cast into concrete to provide fixing points for attachments and structural members. The TIM is the original Reid design with a large foot at the base of the insert (see nominal dimensions).



    The Reid Stainless Steel Metric Threaded Inserts (TCM) are manufactured from premium grade 316 Stainless Steel and suit medium to heavy duty structural applications. Noticably different from the TIMS, this threaded insert has an Elephant Foot™ (original Ramset design).

    Features & Benefits:

    • No cross bar required to develop rated capacity.
    • Resists dynamic loading.
    • Plastic nail plates simplify installation and minimise fouling during the concrete pour.
    File Type File Description
    Reid Metric Threaded Inserts Design Guide Design GuidesThreaded Inserts are designed for casting into concrete and providing fixing points for the attachment of structural members and ancillary fittings to be bolted directly to the concrete structure. Reid supply a range of threaded inserts from M10 to M24 in
    Reid Precast Solutions NZ Product Guide Product GuidesThis document contains product codes and key data for the precast solutions product range.

    Reid™ has been a trusted construction industry supplier for over 100 years.
